AndroidUI组件SlidingTabLayout实现ViewPager页滑动效果

使用SlidingTabLayout需要准备2个类，分别是 SlidingTabLayout，与SlidingTabStrip，，放进项目中时只用修改下包名即可。

效果制作的不是很好。
这篇文章，也是在网上搜了很多资源参考，对 SlidingTabLayout.java和SlidingTabStrip.java进行了修改。大家可以更改他的格式字体大小、选中状态，分割线调整等等。先上传这两个文件，改动支出都做了注释。
SlidingTabLayout.java

/* * Copyright （C） 2013 The Android Open Source Project * * Licensed under the Apache License, Version 2.0 （the "License"）; * you may not use this file except in compliance with the License. * You may obtain a copy of the License at * *http://www.apache.org/licenses/LICENSE-2.0 * * Unless required by applicable law or agreed to in writing, software * distributed under the License is distributed on an "AS IS" BASIS, * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. * See the License for the specific language governing permissions and * limitations under the License. */package com.example.my.slidingtablayout;import android.content.Context;import android.content.res.TypedArray;import android.graphics.Color;import android.graphics.Typeface;import android.os.Build;import android.support.v4.view.PagerAdapter;import android.support.v4.view.ViewPager;import android.util.AttributeSet;import android.util.TypedValue;import android.view.Gravity;import android.view.LayoutInflater;import android.view.View;import android.widget.HorizontalScrollView;import android.widget.LinearLayout;import android.widget.TextView;/** * To be used with ViewPager to provide a tab indicator component which give constant feedback as to * the user"s scroll progress. * <p> * To use the component, simply add it to your view hierarchy. Then in your * {@link android.app.Activity} or {@link android.support.v4.app.Fragment} call * {@link #setViewPager（ViewPager）} providing it the ViewPager this layout is being used for. * <p> * The colors can be customized in two ways. The first and simplest is to provide an array of colors * via {@link #setSelectedIndicatorColors（int...）} and {@link #setDividerColors（int...）}. The * alternative is via the {@link TabColorizer} interface which provides you complete control over * which color is used for any individual position. * <p> * The views used as tabs can be customized by calling {@link #setCustomTabView（int, int）}, * providing the layout ID of your custom layout. */public class SlidingTabLayout extends HorizontalScrollView { /*** Allows complete control over the colors drawn in the tab layout. Set with* {@link #setCustomTabColorizer（TabColorizer）}.*/ public interface TabColorizer {/** * @return return the color of the indicator used when {@code position} is selected. */int getIndicatorColor（int position）;/** * @return return the color of the divider drawn to the right of {@code position}. */int getDividerColor（int position）; } private static final int TITLE_OFFSET_DIPS = 24; private static final int TAB_VIEW_PADDING_DIPS = 16; //内边距 private static int TAB_VIEW_TEXT_SIZE_SP = 16; //字体大小 private int mTitleOffset; private int mTabViewLayoutId; private int mTabViewTextViewId; // 定义两种需要添加的选项卡颜色 private int mDefaultTextColor; private int mSelectedTextColor; private ViewPager mViewPager; private ViewPager.OnPageChangeListener mViewPagerPageChangeListener; private final SlidingTabStrip mTabStrip; public SlidingTabLayout（Context context） {this（context, null）; } public SlidingTabLayout（Context context, AttributeSet attrs） {this（context, attrs, 0）; } public SlidingTabLayout（Context context, AttributeSet attrs, int defStyle） {super（context, attrs, defStyle）;// 获取选项卡颜色，如果未定义的话，则使用主题默认的颜色TypedArray a = context.obtainStyledAttributes（attrs,R.styleable.SlidingTabLayout）;int defaultTextColor = a.getColor（R.styleable.SlidingTabLayout_android_textColorPrimary, 0）;mDefaultTextColor = a.getColor（R.styleable.SlidingTabLayout_textColorTabDefault, defaultTextColor）;mSelectedTextColor = a.getColor（R.styleable.SlidingTabLayout_textColorTabSelected ,defaultTextColor）;a.recycle（）;// Disable the Scroll BarsetHorizontalScrollBarEnabled（false）;// Make sure that the Tab Strips fills this ViewsetFillViewport（true）;mTitleOffset = （int） （TITLE_OFFSET_DIPS * getResources（）.getDisplayMetrics（）.density）;mTabStrip = new SlidingTabStrip（context）;addView（mTabStrip, LayoutParams.MATCH_PARENT, LayoutParams.WRAP_CONTENT）; } // 在每次选项改变时更新选项卡文本颜色的新方法 private void updateSelectedTitle（int position） {final PagerAdapter adapter = mViewPager.getAdapter（）;for （int i = 0; i < adapter.getCount（）; i++） { final View tabView = mTabStrip.getChildAt（i）; if （TextView.class.isInstance（tabView）） {TextView titleView = （TextView）tabView;boolean isSelected = i == position;titleView.setTextColor（isSelected ? mSelectedTextColor : mDefaultTextColor）; }} } /*** Set the custom {@link TabColorizer} to be used.* <p>* If you only require simple custmisation then you can use* {@link #setSelectedIndicatorColors（int...）} and {@link #setDividerColors（int...）} to achieve* similar effects.*/ public void setCustomTabColorizer（TabColorizer tabColorizer） {mTabStrip.setCustomTabColorizer（tabColorizer）; } /*** Sets the colors to be used for indicating the selected tab. These colors are treated as a* circular array. Providing one color will mean that all tabs are indicated with the same color.*/ public void setSelectedIndicatorColors（int... colors） {mTabStrip.setSelectedIndicatorColors（colors）; } /*** Sets the colors to be used for tab dividers. These colors are treated as a circular array.* Providing one color will mean that all tabs are indicated with the same color.*/ public void setDividerColors（int... colors） {mTabStrip.setDividerColors（colors）; } //...设置字体大小 public void setTitleSize（int size） {this.TAB_VIEW_TEXT_SIZE_SP = size; } /*** Set the {@link ViewPager.OnPageChangeListener}. When using {@link SlidingTabLayout} you are* required to set any {@link ViewPager.OnPageChangeListener} through this method. This is so* that the layout can update it"s scroll position correctly.** @see ViewPager#setOnPageChangeListener（ViewPager.OnPageChangeListener）*/ public void setOnPageChangeListener（ViewPager.OnPageChangeListener listener） {mViewPagerPageChangeListener = listener; } /*** Set the custom layout to be inflated for the tab views.** @param layoutResId Layout id to be inflated* @param textViewId id of the {@link TextView} in the inflated view*/ public void setCustomTabView（int layoutResId, int textViewId） {mTabViewLayoutId = layoutResId;mTabViewTextViewId = textViewId; } /*** Sets the associated view pager. Note that the assumption here is that the pager content* （number of tabs and tab titles） does not change after this call has been made.*/ public void setViewPager（ViewPager viewPager） {mTabStrip.removeAllViews（）;mViewPager = viewPager;if （viewPager ！= null） { viewPager.setOnPageChangeListener（new InternalViewPagerListener（））; populateTabStrip（）;} } /*** Create a default view to be used for tabs. This is called if a custom tab view is not set via* {@link #setCustomTabView（int, int）}.*/ protected TextView createDefaultTabView（Context context） {TextView textView = new TextView（context）;textView.setGravity（Gravity.CENTER）;textView.setTextSize（TypedValue.COMPLEX_UNIT_SP, TAB_VIEW_TEXT_SIZE_SP）;textView.setTypeface（Typeface.DEFAULT_BOLD）;//...这会移除 Holo 的默认背景强调以及选项卡的粗体文本if （Build.VERSION.SDK_INT >= Build.VERSION_CODES.HONEYCOMB） { // If we"re running on Honeycomb or newer, then we can use the Theme"s // selectableItemBackground to ensure that the View has a pressed state TypedValue outValue = new TypedValue（）; getContext（）.getTheme（）.resolveAttribute（android.R.attr.selectableItemBackground, outValue, true）; textView.setBackgroundResource（outValue.resourceId）;}if （Build.VERSION.SDK_INT >= Build.VERSION_CODES.ICE_CREAM_SANDWICH） { // If we"re running on ICS or newer, enable all-caps to match the Action Bar tab style textView.setAllCaps（true）;}int padding = （int） （TAB_VIEW_PADDING_DIPS * getResources（）.getDisplayMetrics（）.density）;textView.setPadding（padding, padding, padding, padding）;return textView; } private void populateTabStrip（） {final PagerAdapter adapter = mViewPager.getAdapter（）;final OnClickListener tabClickListener = new TabClickListener（）;for （int i = 0; i < adapter.getCount（）; i++） { View tabView = null; TextView tabTitleView = null; if （mTabViewLayoutId ！= 0） {// If there is a custom tab view layout id set, try and inflate ittabView = LayoutInflater.from（getContext（））.inflate（mTabViewLayoutId, mTabStrip,false）;tabTitleView = （TextView） tabView.findViewById（mTabViewTextViewId）; } if （tabView == null） {tabView = createDefaultTabView（getContext（））; } if （tabTitleView == null && TextView.class.isInstance（tabView）） {tabTitleView = （TextView） tabView; } tabTitleView.setText（adapter.getPageTitle（i））; //... 设置头部均分 LinearLayout.LayoutParams layoutParams = new LinearLayout.LayoutParams（0, LayoutParams.WRAP_CONTENT, 1.0f）; tabView.setLayoutParams（layoutParams）; tabView.setOnClickListener（tabClickListener）; mTabStrip.addView（tabView）;} } @Override protected void onAttachedToWindow（） {super.onAttachedToWindow（）;if （mViewPager ！= null） { scrollToTab（mViewPager.getCurrentItem（）, 0）;} } private void scrollToTab（int tabIndex, int positionOffset） {final int tabStripChildCount = mTabStrip.getChildCount（）;if （tabStripChildCount == 0 || tabIndex < 0 || tabIndex >= tabStripChildCount） { return;}View selectedChild = mTabStrip.getChildAt（tabIndex）;if （selectedChild ！= null） { // 调用在每次选项改变时更新文本颜色的新方案 updateSelectedTitle（tabIndex）; int targetScrollX = selectedChild.getLeft（） + positionOffset; if （tabIndex > 0 || positionOffset > 0） {// If we"re not at the first child and are mid-scroll, make sure we obey the offsettargetScrollX -= mTitleOffset; } scrollTo（targetScrollX, 0）;} } private class InternalViewPagerListener implements ViewPager.OnPageChangeListener {private int mScrollState;@Overridepublic void onPageScrolled（int position, float positionOffset, int positionOffsetPixels） { int tabStripChildCount = mTabStrip.getChildCount（）; if （（tabStripChildCount == 0） || （position < 0） || （position >= tabStripChildCount）） {return; } mTabStrip.onViewPagerPageChanged（position, positionOffset）; View selectedTitle = mTabStrip.getChildAt（position）; int extraOffset = （selectedTitle ！= null） ? （int） （positionOffset * selectedTitle.getWidth（）） : 0; scrollToTab（position, extraOffset）; if （mViewPagerPageChangeListener ！= null） {mViewPagerPageChangeListener.onPageScrolled（position, positionOffset,positionOffsetPixels）; }}@Overridepublic void onPageScrollStateChanged（int state） { mScrollState = state; if （mViewPagerPageChangeListener ！= null） {mViewPagerPageChangeListener.onPageScrollStateChanged（state）; }}@Overridepublic void onPageSelected（int position） { if （mScrollState == ViewPager.SCROLL_STATE_IDLE） {mTabStrip.onViewPagerPageChanged（position, 0f）;scrollToTab（position, 0）; } if （mViewPagerPageChangeListener ！= null） {mViewPagerPageChangeListener.onPageSelected（position）; }} } private class TabClickListener implements OnClickListener {@Overridepublic void onClick（View v） { for （int i = 0; i < mTabStrip.getChildCount（）; i++） {if （v == mTabStrip.getChildAt（i）） { mViewPager.setCurrentItem（i）; return;} }} }}

SlidingTabStrip.java

/* * Copyright （C） 2013 The Android Open Source Project * * Licensed under the Apache License, Version 2.0 （the "License"）; * you may not use this file except in compliance with the License. * You may obtain a copy of the License at * *http://www.apache.org/licenses/LICENSE-2.0 * * Unless required by applicable law or agreed to in writing, software * distributed under the License is distributed on an "AS IS" BASIS, * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. * See the License for the specific language governing permissions and * limitations under the License. */package com.example.my.slidingtablayout;import android.R;import android.content.Context;import android.graphics.Canvas;import android.graphics.Color;import android.graphics.Paint;import android.util.AttributeSet;import android.util.TypedValue;import android.view.View;import android.widget.LinearLayout;class SlidingTabStrip extends LinearLayout { private static final int DEFAULT_BOTTOM_BORDER_THICKNESS_DIPS = 0; //去除阴影 private static final byte DEFAULT_BOTTOM_BORDER_COLOR_ALPHA = 0x26; private static final int SELECTED_INDICATOR_THICKNESS_DIPS = 4;//设置滚动条的高度 private static final int DEFAULT_SELECTED_INDICATOR_COLOR = 0xFF33B5E5; private static final int DEFAULT_DIVIDER_THICKNESS_DIPS = 1; private static final byte DEFAULT_DIVIDER_COLOR_ALPHA = 0x20; private static final float DEFAULT_DIVIDER_HEIGHT = 0.5f; private final int mBottomBorderThickness; private final Paint mBottomBorderPaint; private final int mSelectedIndicatorThickness; private final Paint mSelectedIndicatorPaint; private final int mDefaultBottomBorderColor; private final Paint mDividerPaint; private final float mDividerHeight; private int mSelectedPosition; private float mSelectionOffset; private SlidingTabLayout.TabColorizer mCustomTabColorizer; private final SimpleTabColorizer mDefaultTabColorizer; SlidingTabStrip（Context context） {this（context, null）; } SlidingTabStrip（Context context, AttributeSet attrs） {super（context, attrs）;setWillNotDraw（false）;final float density = getResources（）.getDisplayMetrics（）.density;TypedValue outValue = new TypedValue（）;context.getTheme（）.resolveAttribute（R.attr.colorForeground, outValue, true）;final int themeForegroundColor = outValue.data;mDefaultBottomBorderColor = setColorAlpha（themeForegroundColor,DEFAULT_BOTTOM_BORDER_COLOR_ALPHA）;mDefaultTabColorizer = new SimpleTabColorizer（）;mDefaultTabColorizer.setIndicatorColors（DEFAULT_SELECTED_INDICATOR_COLOR）;mDefaultTabColorizer.setDividerColors（setColorAlpha（themeForegroundColor,DEFAULT_DIVIDER_COLOR_ALPHA））;mBottomBorderThickness = （int） （DEFAULT_BOTTOM_BORDER_THICKNESS_DIPS * density）;mBottomBorderPaint = new Paint（）;mBottomBorderPaint.setColor（mDefaultBottomBorderColor）;mSelectedIndicatorThickness = （int） （SELECTED_INDICATOR_THICKNESS_DIPS * density）;mSelectedIndicatorPaint = new Paint（）;mDividerHeight = DEFAULT_DIVIDER_HEIGHT;mDividerPaint = new Paint（）;mDividerPaint.setStrokeWidth（（int） （DEFAULT_DIVIDER_THICKNESS_DIPS * density））; } void setCustomTabColorizer（SlidingTabLayout.TabColorizer customTabColorizer） {mCustomTabColorizer = customTabColorizer;invalidate（）; } void setSelectedIndicatorColors（int... colors） {// Make sure that the custom colorizer is removedmCustomTabColorizer = null;mDefaultTabColorizer.setIndicatorColors（colors）;invalidate（）; } void setDividerColors（int... colors） {// Make sure that the custom colorizer is removedmCustomTabColorizer = null;mDefaultTabColorizer.setDividerColors（colors）;invalidate（）; } void onViewPagerPageChanged（int position, float positionOffset） {mSelectedPosition = position;mSelectionOffset = positionOffset;invalidate（）; } @Override protected void onDraw（Canvas canvas） {final int height = getHeight（）;final int childCount = getChildCount（）;final int dividerHeightPx = （int） （Math.min（Math.max（0f, mDividerHeight）, 1f） * height）;final SlidingTabLayout.TabColorizer tabColorizer = mCustomTabColorizer ！= null? mCustomTabColorizer: mDefaultTabColorizer;// Thick colored underline below the current selectionif （childCount > 0） { View selectedTitle = getChildAt（mSelectedPosition）; int left = selectedTitle.getLeft（）; int right = selectedTitle.getRight（）; int color = tabColorizer.getIndicatorColor（mSelectedPosition）; if （mSelectionOffset > 0f && mSelectedPosition < （getChildCount（） - 1）） {int nextColor = tabColorizer.getIndicatorColor（mSelectedPosition + 1）;if （color ！= nextColor） { color = blendColors（nextColor, color, mSelectionOffset）;}// Draw the selection partway between the tabsView nextTitle = getChildAt（mSelectedPosition + 1）;left = （int） （mSelectionOffset * nextTitle.getLeft（） +（1.0f - mSelectionOffset） * left）;right = （int） （mSelectionOffset * nextTitle.getRight（） +（1.0f - mSelectionOffset） * right）; } mSelectedIndicatorPaint.setColor（color）; canvas.drawRect（left, height - mSelectedIndicatorThickness, right, height, mSelectedIndicatorPaint）;}// Thin underline along the entire bottom edgecanvas.drawRect（0, height - mBottomBorderThickness, getWidth（）, height, mBottomBorderPaint）;// Vertical separators between the titlesint separatorTop = （height - dividerHeightPx） / 2;for （int i = 0; i < childCount - 1; i++） { View child = getChildAt（i）; mDividerPaint.setColor（tabColorizer.getDividerColor（i））; canvas.drawLine（child.getRight（）, separatorTop, child.getRight（）, separatorTop + dividerHeightPx, mDividerPaint）;} } /*** Set the alpha value of the {@code color} to be the given {@code alpha} value.*/ private static int setColorAlpha（int color, byte alpha） {return Color.argb（alpha, Color.red（color）, Color.green（color）, Color.blue（color））; } /*** Blend {@code color1} and {@code color2} using the given ratio.** @param ratio of which to blend. 1.0 will return {@code color1}, 0.5 will give an even blend,*0.0 will return {@code color2}.*/ private static int blendColors（int color1, int color2, float ratio） {final float inverseRation = 1f - ratio;float r = （Color.red（color1） * ratio） + （Color.red（color2） * inverseRation）;float g = （Color.green（color1） * ratio） + （Color.green（color2） * inverseRation）;float b = （Color.blue（color1） * ratio） + （Color.blue（color2） * inverseRation）;return Color.rgb（（int） r, （int） g, （int） b）; } private static class SimpleTabColorizer implements SlidingTabLayout.TabColorizer {private int[] mIndicatorColors; //private int[] mDividerColors;//@Overridepublic final int getIndicatorColor（int position） { return mIndicatorColors[position % mIndicatorColors.length];}@Overridepublic final int getDividerColor（int position） { return mDividerColors[position % mDividerColors.length];}void setIndicatorColors（int... colors） { mIndicatorColors = colors;}void setDividerColors（int... colors） { mDividerColors = colors;} }}

上边因为使用了自定义的颜色，所以这里要在attrs.xml声明一下，不然找不到：

<?xml version="1.0" encoding="utf-8"?><resources> <declare-styleable name="SlidingTabLayout"><attr name="android:textColorPrimary" /><attr name="textColorTabDefault" format="color" /><attr name="textColorTabSelected" format="color" /> </declare-styleable></resources>

布局文件也要用到自定义：

<?xml version="1.0" encoding="utf-8"?><LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:tools="http://schemas.android.com/tools" xmlns:app="http://schemas.android.com/apk/res-auto" android:id="@+id/activity_main" android:layout_width="match_parent" android:layout_height="match_parent" android:orientation="vertical" tools:context="com.example.my.slidingtablayout.MainActivity"> <！-- 在上方就在上面，在下方就在下面（tab栏） --> <com.example.my.slidingtablayout.SlidingTabLayoutandroid:id="@+id/sliding"android:layout_width="match_parent"android:layout_height="wrap_content"app:textColorTabDefault="#000000"app:textColorTabSelected="@color/colorAccent"/> <android.support.v4.view.ViewPagerandroid:id="@+id/view_pager"android:layout_width="match_parent"android:layout_height="match_parent"/></LinearLayout>

最后一道就是在你的Activity运用这种开源：可以调整之处也做了说明

package com.example.my.slidingtablayout;import android.graphics.Color;import android.os.Bundle;import android.support.v4.view.PagerAdapter;import android.support.v4.view.ViewPager;import android.support.v7.app.AppCompatActivity;import android.view.View;import android.view.ViewGroup;import android.widget.LinearLayout;import java.util.ArrayList;public class MainActivity extends AppCompatActivity { //创建 颜色数组 用来做viewpager的背景 @Override protected void onCreate（Bundle savedInstanceState） {super.onCreate（savedInstanceState）;setContentView（R.layout.activity_main）;ViewPager pager = （ViewPager） findViewById（R.id.view_pager）;SlidingTabLayout tab = （SlidingTabLayout） findViewById（R.id.sliding）;tab.setDividerColors（Color.TRANSPARENT）; //设置标题的分割线tab.setSelectedIndicatorColors（Color.rgb（51, 181, 229））; //设置滚动条的颜色tab.setTitleSize（18）; //...设置字体的颜色，默认16MyAdapte adapter = new MyAdapte（）;pager.setAdapter（adapter）;tab.setViewPager（pager）; } int[] colors = {0xFF123456, 0xFF654321, 0xFF336699}; class MyAdapte extends PagerAdapter {//可以考虑把这个数组添加到集合里面String[] titles = {"AA", "BB", "CC"};ArrayList<LinearLayout> layouts = new ArrayList<LinearLayout>（）;MyAdapte（） { for （int i = 0; i < 3; i++） {LinearLayout l = new LinearLayout（MainActivity.this）;l.setBackgroundColor（colors[i]）;l.setLayoutParams（new ViewGroup.LayoutParams（ViewGroup.LayoutParams.MATCH_PARENT, ViewGroup.LayoutParams.MATCH_PARENT））;layouts.add（l）; }}@Overridepublic int getCount（） { return layouts.size（）;}@Overridepublic boolean isViewFromObject（View view, Object o） { return view == o;}@Overridepublic Object instantiateItem（ViewGroup container, int position） { LinearLayout l = layouts.get（position）; container.addView（l）; return l;}@Overridepublic void destroyItem（ViewGroup container, int position, Object object） { container.removeView（layouts.get（position））;}@Overridepublic CharSequence getPageTitle（int position） { //...可以返回集合list.get（position）; return titles[position];} }}

以上就是本文的全部内容，希望对大家的学习有所帮助，也希望大家多多支持脚本之家。
